Using the S7-3t TEE Transducer
Philips recommends familiarizing yourself with the controls and parts of the TEE transducer
before using it in an exam. For more information on transducer controls, see “S7-3t TEE
Controls” on page 218.
S7-3t TEE Transducer Parts
1 Distal tip
2 Flexible shaft
3 Transducer connector
Using the S7-3t TEE Transducer
Transesophageal Transducers
EPIQ 7 User Manual 4535 617 25341 217
