S7-3t Controls
1 90-degree rotation indicator
2 Array control
3 Deflection control
4 Deflection lock
5 Neutral position indicators (no deflection)
Unlocked, freewheeling (white)
Locked (red)
Using the S7-3t TEE Transducer
Transesophageal Transducers
EPIQ 7 User Manual 4535 617 25341 219
