Transducer Receptacles
1 Physio probe receptacle
2 Doppler probe receptacle
3 Imaging transducer receptacle
When a transducer is not in use, store it in one of the transducer holders on the system cart.
Always loop transducer cables over the cable hangers to prevent cables from being stepped on
or run over by the cart wheels.
System Components
System Overview
EPIQ 7 User Manual 4535 617 25341 97
