Axioline E product group
8395_en_03 PHOENIX CONTACT 11 / 58
2.4 Axioline E product designation
Structure of the
product designation
Meaning of the
product designation
g
Product
range
Product
group
Network I/O type Extention Network connection
I/O connection
Width in cm/
housing material
AXL E PN DIx 2A M12 6M
EIP DIx DOx
S3 DIOx
ETH IOLx DIx
EC IOL DIx
PB IOL DOx
Example:
AXL E PB DI8 DO4 2A M12 6P
AXL E - IOL DO8 - M12 6P
Abbreviation Meaning
AXL Axioline
E Name of thr product group
PN PROFINET
EIP EtherNet/IP
TM
S3 Sercos
ETH Ethernet (Modbus/TCP)
EC EtherCAT
®
PB PROFIBUS
DIx x digital inputs
DOx x digital outputs
DIx DOx x digitale inputs; x digital outputs
DIOx x freely configurable inputs or outputs
IOL IO-Link
2A Nominal current of an output is 2 A
M12 M12 connector
6M 6 cm wide, metal housing
6P 6 cm wide, plastic housing
