UM EN AXL E SYS INST
48
PHOENIX CONTACT 8395_en_03
5.2.3 Marking of the
Axioline E IO-Link digital input and output devices
It is possible to mark the devices next to the ports (7 in Figure 5-4) zu beschriften. The de-
vices are supplied as standard with nine unprinted marking labels. If you want to swap a la-
bel, you can lift it out of the recess using a screwdriver.
5.2.4 Diagnostic and status indicators of the
Axioline E IO-Link digital input and output devices
Diagnostics The diagnostics indicators (green/yellow/red) indicate whether an error is present or not.
In the event of an error, they indicate the error type and location.
An Axioline E IO-Link digital input and output device works properly when all green indica-
tors light/flash.
Status The status indicators (yellow/red) indicate the signal state of the corresponding IO-Link port
(input/output ).
Phoenix Contact offers the CMS-MARK-WIN software for professional marking,
see Phoenix Contact catalog.
For more detailed information on the diagnostics and status indicators, please refer to the
data sheet for the respective device.
