Description of the Axioline E devices

8395_en_03PHOENIX CONTACT 21 / 58

3.3 Dimensions of screw holes in the fixing clips

The drawing below shows the dimensions of the screw holes in the fixing clips.

Figure 3-7 Dimensions of the screw holes in mm

6.3

7.3
