4.7 Cable connection
Phoenix Contact recommends using the SPEEDCON fast locking system to connect
M12 cables. The fast locking system is quick to install as it is based on the principle of
“Plug & Turn”. With just a half turn you can create the perfect plug-in connection.
The SPEEDCON fast locking system is 100% compatible with all M12 connectors.
Figure 4-12 Connecting M12 connectors
Figure 4-13 Axioline E device with connected M12 connectors
Figure 4-14 Connectors in straight and angled format
