UM EN AXL E SYS INST

20 / 58

PHOENIX CONTACT 8395_en_03

3.2.2 PROFIBUS versions

Figure 3-5 Housing dimensions (mm) of PROFIBUS metal devices with mounting plate

The height is 194.5 mm including the mounting plate. The depth is 38 mm including the

mounting plate.

Figure 3-6 Housing dimensions (mm) of PROFIBUS metal devices

with extended fixing clips

194.5

185

212

30.5

198.5

X21
