5.3.1 Dimensions of the straight IO-Link/analog converter
Figure 5-8 Dimensions in mm
5.3.2 Dimensions of the rectangular IO-Link/analog converter
Figure 5-9 Dimensions in mm
50
16,5
79,5
28
29
16,6
50
66,5
28
29
41
16,6
