Configuration and diagnostics
7278_en_04 PHOENIX CONTACT 3-53
Press "a" to download the new software. The following message appears:
Figure 3-34 XMODEM ready
The switch is now ready for the new firmware. In HyperTerminal, select "Send File" from the
"Transmission" menu.
Figure 3-35 Xmodem - Send File option
--->Phoenix Contact Lean Managed Switch<---
Phoenix Contact GmbH & Co. KG
www.phoenixcontact.com
ENTER ´a´ TO DOWNLOAD SWITCH SOFTWARE USING XMODEM PROTOCOL
ENTER ´c´ TO CONTINUE BOOTING
PxC LMS systemprompt> a
Downloading firmware image with XMODEM over serial port ...
XMODEM Receive: Waiting for Sender ...
-_
Make sure that the protocol is set to "Xmodem", otherwise the transmission will fail.
