FL SWITCH LM ...
3-54
PHOENIX CONTACT 7278_en_04
Clicking "Send" starts the file transfer. The following screen shows the progress of the file
transmission.
Figure 3-36 File transmission with Xmodem
Once the box has closed, a message appears in HyperTerminal. Enter "c" to continue with
the boot process, or trigger a reset using the reset button.
File transmission may take a few minutes. Do not perform any other actions while the box
is open.
