3.3 Technical specifications.
- Number of memory places 500 - 999
- Languages:
West European: English, German, French, Dutch
South European: Italian, Spanish, Portuguese, English
- Treatment time: 0 - 60 minutes
- Dimensions : 424 x 308 x 163 cm
- Weight: 9 kg
- Insulation class: I type BF
- Voltage: 110, 127,220, 230 of 240 Volt AC, frequency 50 - 60 Hz, settings via an external switch
- Power consumption: maximum 96 VA
- Help screen for explanation on the selected electrotherapeutic current or parameter
- 2 independent channels with possibility to set different therapy forms per channel
- Extensive indication list with recommended therapy programs
- Sequential therapy forms
- Possibility to set various system settings and program parameters to the personal preference
- Built-in cable and electrode test
- Solid metal casing (Faraday’s cage)
- Cover: ABS
Ultrasound output: probe model 891
ERA: 0,6 cm² at 1 MHz
ERA: 1,0 cm² at 3 MHz
Frequency: 1 and 3 MHz
BNR < 5
Pulsfrequency: 100 Hz
Duty Cycle: 10%, 20%, 30%, 40%, 50%, 100%
Ultrasound output: probe model 892
ERA: 4,0 cm² at 1 MHz
ERA: 4,8 cm² at 3 MHz
Frequency: 1 and 3 MHz
BNR: <8
Pulsfrequency: 100 Hz
Duty Cycle: 10%, 20%, 30%, 40%, 50%, 100%
3.4 Different symbols.
3.4.1 Symbols on the front of the Guidance E/C
Therapy menu
Guidance menu
Memory
System settings
Help ?
Go back
Stop
Pause
Amplitude
