With vacuum selected the yellow lights next to the vacuum outputs turn on when the
intensity of the corresponding channel is increased from zero
Select now program number 24 in the same way as described above (isoplanar vector
field). Turn up the intensity to maximum with the control knob
Pass Fail
The output signals as seen on the oscilloscope correspond with figure 3 and 4
The output currents matches the values shown on the display within ±10%
Select now program number 111 in the same way as described above (diadynamic DF).
Turn up the intensity to maximum with the control knob
Pass Fail
The output signals as seen on the oscilloscope correspond with figure 2
The output currents matches the values shown on the display within ±10%
7.4.4 Electrical Safety Test According to VDE 0751
Parameter Meas. Value Limit Comments Pass Fail
Protective earth resistance
Ω < 0.2 Ω
Enclosure leakage current µA < 1000 µA
Patient leakage current µA < 5000 µA
7.4.5 Result of safety inspection
The Guidance E/C with serial number ...................................... has passed / failed
∗
Place: Safety Inspector For the User
........................................ Name: Name:
Date: Sign: Sign:
........................................
Phyaction Guidance E/C – service manual version 0.5 Page 28
