15. SPARE PARTS
15.1 Phyaction Guidance E/C
Unit type : PHYACTION GUIDANCE E/C incl. std.toebeh. (115-230V)
Reference number : 114674/ 116199
Version : 10
Ordering number Description Service
code
15519 Water outlet sealer GUIDANCE (M3x3mm
black)
S
30017 Water tank assembly S
30018 LCD screen mounted (only housing) S
30343 PCB vacuum (front PCB) S
30344 PCB main S
31253 Connectorplate (plastic) S
31258 Dose knob vacuum (plastic) S
31260 Frontpanel 800 (topcover plastic), V1.2 S
31511 Tube watertank outlet (30cm) S
31559 Cableassembly encoder 800 S
31561 Cableassembly output ET 800 S
31562 Cableassembly main-output 800 S
32480 Water drain connector plug 4mm S
35705 Fuse 2A, 5X20mm, Slo-Blo S
37224 Vacuum outlet connector chromium (1 piece) S
30015 Mains entrance 0
30016 Silicone keypad 800 0
30643 Subfront connectorplate 800 (metal) 0
30646 Foil LCD module 800 0
30650 Foil for fan 0
30651 Bottom chassis 800, version 1.2 (metal) 0
30653 Subfront 800 versie 1.2 (metal topcover
subplate)
0
31252 Led glass, 1 led, met borst 0
31256 Rear cover LCD module 800 0
31257 Knob intensity encoder 0
31556 Cableassembly backlight 800 0
31557 Cableassembly watertank 800 0
31558 Cableassembly valves 800 0
31560 Cableassembly RS232 800 0
31563 Cableassembly main-IO PCB 800 0
32479 EMC profile self-adhesive 0
32483 Friction hinge LCD assembly 0
33909 Mains tranformer, ringcore 500/800 0
34213 LED 3mm, yellow 0
34214 LED 3mm, green 0
35402 Vacuum pressure sensor Motorola MPX2050DP 0
38103 Pump 800 serie 0
38104 Fan 12V incl. connector 0
38105 Valve, 0.65mm complete 0
Phyaction Guidance E/C – service manual version 0.5 Page 58
