Replace the cable if the test gives a negative result.
Perform the same test for the other cables.
/ Due to lime residues a bad contact between the vacuum cable and the output plug may appear,
resulting in a negative test of the vacuum cable. In order to prevent this, GymnaUniphy nv.
recommends to remove all the vacuum cables once a week, in order to scratch off the lime residues.
8.7.2 Electrode cable test.
Select ‘cable test’ in the system settings menu
.
Connect the patient cable to the channel A (without the plate electrodes) and make a short-circuit
with the supplied connector.
Turn up the intensity to 10 V and move with the plugs and cable to detect a bad contact.
The unit will now display whether the cable is ‘ok’ or ‘bad’.
Phyaction Guidance E/C – service manual version 0.5 Page 33
