3.4.7 Symbols currents
Direct current
Iontophoresis
Medium frequency rectangular current
Rectangular pulsed current
Triangular pulsed current
Conventional TENS
Low frequency TENS
Brief intense TENS
Random TENS
Burst TENS
Rectangular surge current
Triangular surge current
Biphasic surge current
Biphasic intrapulse interval surge current
2-pole interferential surge current
Russian stimulation
Classical interferential surge current
MF (Diadynamic)
RS (Diadynamic)
DF (Diadynamic)
CP (Diadynamic)
LP (Diadynamic)
2-pole interferential current
Isoplanar vector field
Dipole vector field
Classical interferential current
Rheobase and Chronaxie
CH
Rheobase and A.Q.
AQ
S-D curve rectangular pulse
S-D
S-D curve triangular pulse
S-D
S-D curve rectangular and triangular pulse
S-D
3.4.8 Parameter symbols
Polarity for plate electrodes red-, red+
Alternating polarity for plate electrodes
Polarity for vacuum electrodes
Alternating polarity for vacuum electrodes
Vacuum rhythm: continuous
1,5 s high, 1,5 s low
1,5 s high, 3 s low
1,5 s high, 4,5 s low
