Operation
OperatingManualPNOZs50
1002194EN02
57
O2+, O2-
Y20
Y21
Error
Y10/Y11
Q
1 -> 0
On
On
t
O2+, O2- O1+, O1-
O3
Fig.:Resetfaultwithdualchannelload
Legend:
}
ErrorY10/Y11:FaultatY10/Y11,loadshutsdown
}
Q1>0:Fault:ResetfaultatY21
}
OnO2+,O2:Switchloadon;beforeswitchingon,Y20andY21mustbothbeat"0"
}
OnO1+,O1:Switchloadon;beforeswitchingon,Y10andY11mustbothbeat"0"
}
O3:Faultsignaloutput
