Function description
Operating Manual PSENmlock mini, PSEN mlm 1 sa 1.1/2.1/2.2
1005802-EN-02-Draft
| 14
Fig.: Example: External attachment of safety switch and actuator a (left-hand side mounting)
Safety switch and actuator b, internal attachment
Legend
[A] Safety switch and actuator b (front mounting, internal attachment)
Gate closed
[B] Safety switch and actuator b (front mounting, internal attachment)
Gate open
[C] Actuator b
[D] Safety switch
