Operating Manual PSENmlock mini, PSEN mlm 1 sa 1.1/2.1/2.2
1005802-EN-02-Draft
| 63
13 Technical details
Safety switch PSEN mlm 1 sa with actuator a
General 6K000012 6K000013 6K000014
Certifications CE, FCC, IC, TÜV, cULus
Listed
CE, FCC, IC, TÜV, cULus
Listed
CE, FCC, IC, TÜV, cULus
Listed
Sensor's mode of opera-
tion
Transponders Transponders Transponders
Coding level in accord-
ance with EN ISO 14119
High High High
Design in accordance with
EN ISO 14119
4 4 4
Classification in accord-
ance with EN 60947-5-3
PDDB PDDB PDDB
Pilz coding type coded fully coded uniquely coded
Transponders 6K000012 6K000013 6K000014
Frequency band 127 kHz +/- 3 kHz 127 kHz +/- 3 kHz 127 kHz +/- 3 kHz
Max. transmitter output 15 mW 15 mW 15 mW
Electrical data 6K000012 6K000013 6K000014
Supply voltage
Voltage 24 V 24 V 24 V
Kind DC DC DC
Type of power supply SELV/PELV SELV/PELV SELV/PELV
Voltage tolerance -22,5 %/+20 % -22,5 %/+20 % -22,5 %/+20 %
Output of external
power supply (DC) 0,5 W 0,5 W 0,5 W
Max. switching frequency 0,5 Hz 0,5 Hz 0,5 Hz
Max. solenoid current for t
< 150 ms
1,15 A 1,15 A 1,15 A
Max. cable capacitance at
the safety outputs
No-load, PNOZ with re-
lay contacts 40 nF 40 nF 40 nF
PNOZmulti, PNOZelog,
PSS 70 nF 70 nF 70 nF
Max. inrush current im-
pulse
Current pulse, A1 8,4 A 8,4 A 8,4 A
Pulse duration, A1 0,0105 ms 0,0105 ms 0,0105 ms
Max. unit fuse protection
in accordance with UL
1,5 A 1,5 A 1,5 A
No-load current 20 mA 20 mA 20 mA
Inputs 6K000012 6K000013 6K000014
Quantity 4 4 4
Voltage at inputs 24 V DC 24 V DC 24 V DC
Current at solenoid input 4 mA 4 mA 4 mA
Input current range 2 - 2,6 mA 2 - 2,6 mA 2 - 2,6 mA
