Technical details
Operating Manual PSENmlock mini, PSEN mlm 1 sa 1.1/2.1/2.2
1005802-EN-02-Draft
| 64
Inputs 6K000012 6K000013 6K000014
Potential isolation
between input and internal
module bus voltage
No No No
Semiconductor outputs 6K000012 6K000013 6K000014
OSSD safety outputs 2 2 2
Signal outputs 1 1 1
Switching current per out-
put
100 mA 100 mA 100 mA
Breaking capacity per out-
put
2,4 W 2,4 W 2,4 W
Potential isolation from
system voltage
No No No
Short circuit-proof Yes Yes Yes
Residual current at out-
puts
100 µA 100 µA 100 µA
Voltage drop at OSSDs 1,25 V 1,25 V 1,25 V
Conditional rated short cir-
cuit current
100 A 100 A 100 A
Lowest operating current 1 mA 1 mA 1 mA
Utilisation category in ac-
cordance with EN
60947-1
DC-12 DC-12 DC-12
Times 6K000012 6K000013 6K000014
Max. test pulse duration,
safety outputs
450 µs 450 µs 450 µs
Switch-on delay
after UB is applied 1,2 s 1,2 s 1,2 s
Inputs typ. 40 ms 40 ms 40 ms
Inputs max. 45 ms 45 ms 45 ms
Actuator typ. 770 ms 770 ms 770 ms
Actuator max. 800 ms 800 ms 800 ms
Delay-on de-energisation
Inputs typ. 5 ms 5 ms 5 ms
Inputs max. 5 ms 5 ms 5 ms
Risk time in accordance
with EN 60947-5-3
100 ms 100 ms 100 ms
Processing time activate/
deactivate guard locking
1.000 ms 1.000 ms 1.000 ms
Environmental data 6K000012 6K000013 6K000014
Ambient temperature
in accordance with the
standard EN 60068-2-14 EN 60068-2-14 EN 60068-2-14
Temperature range -10 - 60 °C -10 - 60 °C -10 - 60 °C
Storage temperature
in accordance with the
standard EN 60068-2-1/-2 EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -25 - 70 °C -25 - 70 °C -25 - 70 °C
