Technical details
Operating Manual PSENmlock mini, PSEN mlm 1 sa 1.1/2.1/2.2
1005802-EN-02-Draft
| 65
Environmental data 6K000012 6K000013 6K000014
Climatic suitability
in accordance with the
standard EN 60068-2-78 EN 60068-2-78 EN 60068-2-78
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Max. operating height
above SL
2000 m 2000 m 2000 m
EMC EN 301489-1 V2.1.1, EN
55011: class A, EN
60947-5-2, EN 60947-5-3
EN 301489-1 V2.1.1, EN
55011: class A, EN
60947-5-2, EN 60947-5-3
EN 301489-1 V2.1.1, EN
55011: class A, EN
60947-5-2, EN 60947-5-3
Vibration
in accordance with the
standard EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Frequency 10 - 55 Hz 10 - 55 Hz 10 - 55 Hz
Amplitude 1 mm 1 mm 1 mm
Shock stress
in accordance with the
standard EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Number of shocks 3 3 3
Acceleration 30g 30g 30g
Duration 11 ms 11 ms 11 ms
Airgap creepage
Overvoltage category II II II
Pollution degree 2 2 2
Rated insulation voltage 75 V 75 V 75 V
Rated impulse withstand
voltage
1 kV 1 kV 1 kV
Protection type
Housing IP65, IP67 IP65, IP67 IP65, IP67
Mechanical data 6K000012 6K000013 6K000014
Escape release available No No No
Mechanical life 1,000,000 cycles 1,000,000 cycles 1,000,000 cycles
Holding force FZh
in Z-direction 1500 N 1500 N 1500 N
in X-direction 1950 N 1950 N 1950 N
Holding force F1Max in
accordance with ISO
14119
in Z-direction 3000 N 3000 N 3000 N
in X-direction 3900 N 3900 N 3900 N
Latching force 11 N 11 N 11 N
Max. vertical offset +/-0,25 mm +/-0,25 mm +/-0,25 mm
Max. lateral offset +/- 1,0 mm +/- 1,0 mm +/- 1,0 mm
Max. angular offset
around the X axis
+/-3,1 deg +/-3,1 deg +/-3,1 deg
Max. angular offset
around the Y axis
-5/+12 deg -5/+12 deg -5/+12 deg
