Technical details
Operating Manual PSENmlock mini, PSEN mlm 1 sa 1.1/2.1/2.2
1005802-EN-02-Draft
| 66
Mechanical data 6K000012 6K000013 6K000014
Max. angular offset
around the Z axis
+/-2,3 deg +/-2,3 deg +/-2,3 deg
Max. offset in closing dir-
ection
+/-2 mm +/-2 mm +/-2 mm
Max. retract speed of ac-
tuator
0,3 m/s 0,3 m/s 0,3 m/s
Actuator 1 PSEN mlm actuator a PSEN mlm actuator a PSEN mlm actuator a
Min. distance between
safety switches
35 mm 35 mm 35 mm
Connection type M12, 12-pin male con-
nector
M12, 12-pin male con-
nector
M12, 12-pin male con-
nector
Max. cable length 45 m 45 m 45 m
Material Stainless steel, plastic,
galvanised steel, die
cast zinc
Stainless steel, plastic,
galvanised steel, die
cast zinc
Stainless steel, plastic,
galvanised steel, die
cast zinc
Max. fixing screws torque
settings
6 - 6,5 Nm 6 - 6,5 Nm 6 - 6,5 Nm
Min. gate radius 200 mm 200 mm 200 mm
Dimensions
Height 157,5 mm 157,5 mm 157,5 mm
Width 30,4 mm 30,4 mm 30,4 mm
Depth 30,4 mm 30,4 mm 30,4 mm
Actuator dimensions
Height 35,5 mm 35,5 mm 35,5 mm
Width 30,4 mm 30,4 mm 30,4 mm
Depth 58,5 mm 58,5 mm 58,5 mm
Weight of safety switch 425 g 425 g 425 g
Weight of actuator 175 g 175 g 175 g
Weight 600 g 600 g 600 g
Safety switch PSEN mlm 1 sa with actuator b
General 6K000018 6K000019 6K000020
Certifications CE, FCC, IC, TÜV, cULus
Listed
CE, FCC, IC, TÜV, cULus
Listed
CE, FCC, IC, TÜV, cULus
Listed
Sensor's mode of opera-
tion
Transponders Transponders Transponders
Coding level in accord-
ance with EN ISO 14119
High High High
Design in accordance with
EN ISO 14119
4 4 4
Classification in accord-
ance with EN 60947-5-3
PDDB PDDB PDDB
Pilz coding type coded fully coded uniquely coded
Transponders 6K000018 6K000019 6K000020
Frequency band 127 kHz +/- 3 kHz 127 kHz +/- 3 kHz 127 kHz +/- 3 kHz
Max. transmitter output 15 mW 15 mW 15 mW
