Technical details
Operating Manual PSENmlock mini, PSEN mlm 1 sa 1.1/2.1/2.2
1005802-EN-02-Draft
| 67
Electrical data 6K000018 6K000019 6K000020
Supply voltage
Voltage 24 V 24 V 24 V
Kind DC DC DC
Type of power supply SELV/PELV SELV/PELV SELV/PELV
Voltage tolerance -22,5 %/+20 % -22,5 %/+20 % -22,5 %/+20 %
Output of external
power supply (DC) 0,5 W 0,5 W 0,5 W
Max. switching frequency 0,5 Hz 0,5 Hz 0,5 Hz
Max. solenoid current for t
< 150 ms
1,15 A 1,15 A 1,15 A
Max. cable capacitance at
the safety outputs
No-load, PNOZ with re-
lay contacts 40 nF 40 nF 40 nF
PNOZmulti, PNOZelog,
PSS 70 nF 70 nF 70 nF
Max. inrush current im-
pulse
Current pulse, A1 8,4 A 8,4 A 8,4 A
Pulse duration, A1 0,0105 ms 0,0105 ms 0,0105 ms
Max. unit fuse protection
in accordance with UL
1,5 A 1,5 A 1,5 A
No-load current 20 mA 20 mA 20 mA
Inputs 6K000018 6K000019 6K000020
Quantity 4 4 4
Voltage at inputs 24 V DC 24 V DC 24 V DC
Current at solenoid input 4 mA 4 mA 4 mA
Input current range 2 - 2,6 mA 2 - 2,6 mA 2 - 2,6 mA
Potential isolation
between input and internal
module bus voltage
No No No
Semiconductor outputs 6K000018 6K000019 6K000020
OSSD safety outputs 2 2 2
Signal outputs 1 1 1
Switching current per out-
put
100 mA 100 mA 100 mA
Breaking capacity per out-
put
2,4 W 2,4 W 2,4 W
Potential isolation from
system voltage
No No No
Short circuit-proof Yes Yes Yes
Residual current at out-
puts
100 µA 100 µA 100 µA
Voltage drop at OSSDs 1,25 V 1,25 V 1,25 V
Conditional rated short cir-
cuit current
100 A 100 A 100 A
Lowest operating current 1 mA 1 mA 1 mA
