Technical details
Operating Manual PSENmlock mini, PSEN mlm 1 sa 1.1/2.1/2.2
1005802-EN-02-Draft
| 68
Semiconductor outputs 6K000018 6K000019 6K000020
Utilisation category in ac-
cordance with EN
60947-1
DC-12 DC-12 DC-12
Times 6K000018 6K000019 6K000020
Max. test pulse duration,
safety outputs
450 µs 450 µs 450 µs
Switch-on delay
after UB is applied 1,2 s 1,2 s 1,2 s
Inputs typ. 40 ms 40 ms 40 ms
Inputs max. 45 ms 45 ms 45 ms
Actuator typ. 770 ms 770 ms 770 ms
Actuator max. 800 ms 800 ms 800 ms
Delay-on de-energisation
Inputs typ. 5 ms 5 ms 5 ms
Inputs max. 5 ms 5 ms 5 ms
Risk time in accordance
with EN 60947-5-3
100 ms 100 ms 100 ms
Processing time activate/
deactivate guard locking
1.000 ms 1.000 ms 1.000 ms
Environmental data 6K000018 6K000019 6K000020
Ambient temperature
in accordance with the
standard EN 60068-2-14 EN 60068-2-14 EN 60068-2-14
Temperature range -10 - 60 °C -10 - 60 °C -10 - 60 °C
Storage temperature
in accordance with the
standard EN 60068-2-1/-2 EN 60068-2-1/-2 EN 60068-2-1/-2
Temperature range -25 - 70 °C -25 - 70 °C -25 - 70 °C
Climatic suitability
in accordance with the
standard EN 60068-2-78 EN 60068-2-78 EN 60068-2-78
Humidity 93 % r. h. at 40 °C 93 % r. h. at 40 °C 93 % r. h. at 40 °C
Max. operating height
above SL
2000 m 2000 m 2000 m
EMC EN 301489-1 V2.1.1, EN
55011: class A, EN
60947-5-2, EN 60947-5-3
EN 301489-1 V2.1.1, EN
55011: class A, EN
60947-5-2, EN 60947-5-3
EN 301489-1 V2.1.1, EN
55011: class A, EN
60947-5-2, EN 60947-5-3
Vibration
in accordance with the
standard EN 60947-5-2 EN 60947-5-2 EN 60947-5-2
Frequency 10 - 55 Hz 10 - 55 Hz 10 - 55 Hz
Amplitude 1 mm 1 mm 1 mm
