12 Dimensions
Safety switch PSEN mlm x ba/sa 1.1/2.1/2.2
30.4
6
146.5
157.5
SW4
(50.3)
(13.2)
15.2
30
16.2
30
15.2
30.4
Fig.: Safety switch
