Installation
Operating Manual PSENmlock mini, PSEN mlm 1 sa 1.1/2.1/2.2
1005802-EN-02-Draft
| 49
} Large gate radius R
} Little play in the gate bearing
} Gate sags very little
INFORMATION
The insertion of the actuator into the safety switch is influenced by the
above factors. For this reason we recommend you use 3D data to inspect
the installation situation, see www.pilz.com.
NOTICE
Auxiliary release must be reachable
On the safety switch, ensure that the auxiliary release screw is reachable
with an Allen key (SW4) on one of the two sides when the gate/cover/flap is
closed.
