Installation
Operating Manual PSENmlock mini, PSEN mlm 1 sa 1.1/2.1/2.2
1005802-EN-02-Draft
| 53
Fig.: Safety switch installed on mounting bracket and actuator on mounting plate
Legend
[1] Mounting plate for actuator b
[2] Actuator b (mounting using 2 screws, a one-way screw optional)
[3] Safety switch
[4] Bracket for safety switch (Mounting using 2 screws)
[1] [4] PSENmlmmountingset1 (material number 6K000021)
