Integrator Mode
7) Setting the brightness enhancement at the screen center
Bright enhance is a function that enhances and/or corrects the brightness of the central part of the screen.
This setting can be performed as described below while receiving video or PC signals.
When it is desired to make the screen brighter = Set ON.
When it is desired to restore the normal condition = Set OFF.
1 Enter the integrator mode (refer to section 5.4.1, “About the
integrator mode”.)
The ID number of the unit of adjustment items will be indicated
in the upper right corner of the screen where “– –” is displayed
in the illustration.
Select OPTION 1.
2 Move the cursor to BRIGHT ENHANCE (VIDEO or PC), and
change the mode with the SET button.
(NOTE) This is selected automatically in line with the current
input signal type (video or PC).
Pressing the SET button toggles the BRIGHTNESS
ENHANCE mode back and forth between ON and OFF.
BRIGHT ENHANCE (VIDEO or PC) applies to all inputs
(INPUTs 1 to 4).
Select EXIT in screen 2 to return to screen 1.
WHITE BAL.
MENU
SCREEN
SIDE MASK
3OPTION 1
OPTION 2
SUB VOLUME
G LEVEL
:
128
B LEVEL
:
128
V. SIZE
:
128
CLK FRQ :
– – –
CLK PHS :
– – –
DEFAULT
R LEVEL
:
128
MENU : MENU OFF
5∞ 3 : SELECT
ALL DEFAULT
– –
OPTION 1
OPTION 2
SUB VOLUME
G LEVEL
:
128
B LEVEL
:
128
V. SIZE
:
128
CLK FRQ :
– – –
CLK PHS :
– – –
DEFAULT
R LEVEL
:
128
MENU : MENU OFF
EXIT
DEFAULT
– –
MIRROR MODE : OFF
BRIGHT ENHANCE
3 VIDEO : OFF
COLOR MODE : 1
PC : OFF
]
Screen 1
]
Screen 2
Factory preset: VIDEO : OFF
PC : OFF
