118
Integrator Mode
8) Setting OSD display
This is a function that suppresses the OSD display (INPUT display, etc.) in normal operating mode.
When “OSD: OFF” is set, the following OSD displays are enabled.
1 MENU display (Menu mode, integrator mode, and RS-232C adjustment mode)
2 Warning just before the Power Save feature comes on
3 High internal temperature warning (THERMAL WARNING! PLEASE SHUT DOWN.)
4 Display announcing KEY LOCK is set; also display announcing the setting of KEY LOCK/UNLOCK
When uneasy about automatically operating directions, etc., set OSD: OFF.
Factory preset : ON
1 Enter the integrator mode (refer to section 5.4.1, “About
the integrator mode”).
The ID number of the unit of adjustment items will be indicated
in the upper right corner of the screen, where “– –” is displayed
in the illustration.
Select OPTION 2.
2 Move the cursor to “OSD” and change the mode with the
SET button.
Pressing the SET button toggles the OSD mode between
ON and OFF.
OSD mode applies to all inputs (INPUTs 1 to 4).
Select EXIT in screen 2 to return to screen 1.
WHITE BAL.
MENU
SCREEN
SIDE MASK
OPTION 1
3OPTION 2
SUB VOLUME
ALL DEFAULT
– –
OPTION 2
EXIT
– –
BAUD RATE : 4 8 0 0 BPS
FULL MASK : OFF
FAN CONTROL : AUTO
TEMPERATURE :
3OSD : ON
HOUR METER : 3 4 5 HRS
]
Screen 1
]
Screen 2
