8
2.2 External Dimensions
Weight: 40.3 kg (without attachment stand)
Material: Front: Resin; Rear frame: Resin; Rear cover: Aluminum, Front protector panel: acrylic
Treatment: Front: Paint; Rear frame: Paint; Rear cover: Paint (All paints are Pioneer original colors)
For packaging information, refer to 3.3.2 “Unpacking”.
: Center of gravity
(Unit: mm)
External Dimensions
1162
104 590 104
150150
250250
660
2-M8 (special screw for anchoring plain stand)
Rear View
496
18-M8 (
φ
16 mm, with hole rivet)
609
1218
(1291)
628
1128
357
Light sensor for the remote
98
65
MAIN POWER switch
Centering
Unit operating
panel
714
31.4
Effective screen dimensions
1098
900
Terminal area dimensions
Effective screen dimensions
620.5
