Plasma Display Ceiling Suspension Hardware (one-side type): PDK-5002
4.5 Plasma Display Ceiling Suspension Hardware (one-side type): PDK-5002
4.5.1 Specifications
External dimensions ................. 1218 (W) × 300 (D) × 1162 (H) mm
(with plastic display in horizontal position)
Weight ....................................... 14.6 kg (mounting hardware only)
54.9 kg (mounting hardware and Plasma display)
Adjustable range of angles ...... Horizontal to 25 degrees below horizontal, 45 degrees left/right
Material...................................... Steel pipe for general structure (STK-MR)
Finish.......................................... Semi-matte black paint (Original Pioneer color)
Package dimensions ................. 1270 (W) × 725 (D) × 230 (H) mm
Package weight......................... 24.0 kg
Accessories
Monitor mount bolt ............................................. × 6
Flange nut ........................................................... × 6
Hexagonal socket head bolt (M5 × 16) ................ × 1
Hexagonal socket head bolt (M6 × 10) ................ × 3
Hexagonal socket head bolt (M6 × 30) ................ × 1
Hexagonal socket head bolt (M8 × 75) ................ × 2
Hexagonal socket head bolt (M10 × 85) .............. × 2
Flat washer, φ 8 ................................................... × 2
Flat washer,
φ 10 ................................................. × 2
Spring washer,
φ 8 .............................................. × 2
Spring washer,
φ 10 ............................................ × 2
Hole cover ........................................................... × 1
Spacer ................................................................. × 1
Pattern ................................................................. × 1
Operating instructions ......................................... × 1
Mount contractor contract form .......................... × 1
The appropriate types of screws and other mounting hardware will depend on the strength and composition of the
ceiling. Prepare them separately.
✩ Operating Temperature Restrictions
• Ambient Temperature: 0 to 40 °C
✩ Operating Temperature Restrictions for Upside-Down Installations
• Ambient temperature: 0 to 40 °C
• Other factors: Maintain sufficient clearance between the display and the wall (at least 300 mm)
✩ Operating temperature restrictions for when the speaker system (PDP-S03-LR) is attached.
• Ambient temperature: 0 to 40 °C
