4.5.2 External Dimensions
Unit: mm
Plasma Ceiling Suspension Hardware (one-side type): PDK-5002
25°
12.2
This circle shows the path that the outermost part
of the plasma display follows when it is rotated
about a vertical axis after having been tilted
sideways by 25°. (Without optional speaker.)

Pioneer PDP-502MX Specifications

General

Brand	Pioneer
Model	PDP-502MX
Category	Monitor
Language	English
