52
Table-top Stand: PDK-5001
4.4.3 Dimensions (* with Plasma Display Monitor PDP-502MX installed)
Unit: mm
1218
400
36
4.4.2 Mount locations for floor-fastening screws
* Secure the assembly to the floor using M6 screws at least 20 mm long.
108
292
152 533
*51
*765
700
469
558
656.6
325
130.7
30
179
714
98
65
*123
