Special installation (When the display is put in a box)
A
A
B
B
CD
B+
30 mm
B+
50 mm
A
+50 mm
1118 mm or moreA
+50 mm
750 mm or more
Mesh with aperture effi-
ciency of 50% or more
Rear view (the following area should be made of mesh)
Outside air temperature mea-
suring point
Intake
side
Exhaust
side
10mm
A ≥ 50
B ≥ 50
C ≥ 10
D ≥ 50
100 mm
or more
100
mm
A+70mm
10mm
