Speaker System
Plasma display ceiling
suspension hardware
Washer,
φ
25
(supplied with optional speaker)
R730
R689
45°
45°
Maximum sideways tilt: 45°
Monitor mount bolt
(supplied with ceiling-suspension
plasma display mounting hardware)
Figure 3
This circle shows the path that the outermost part of the plasma
display follows when it is rotated about a vertical axis after having
been tilted sideways by 25°.
This circle shows the path that the outermost part of the plasma
display follows when it is rotated about a vertical axis after having
been tilted sideways by 25°.
