Pioneer pdp-506hdg User Manual

51
En
Appendix
12
English
Signal names for 15-pin mini D-sub
connecter
Standard Channel Allocation Selections for the Countries and Regions
Pin No. Signal name
1R
2G
3B
4 Not connected
5 Not connected
6 GND (ground)
7 GND (ground)
8 GND (ground)
15
14
13
12
9
11
10
8
7
6
5
4 3
2
1
(Front view)
9+5V
10 GND (ground)
11 Not connected
12 SDA
13 HD
14 VD
15 SCL
Pin No. Signal name
Region Standard Channel Allocation Selection
Taiwan Cable (US Type)
Hong Kong Normal
Philippines Cable (US Type)
Thailand Normal
Malaysia Normal
Singapore Normal
Indonesia Normal
Saudi Arabia Normal
Israel Normal
Lebanon Normal
United Arab Emirates Normal
Mexico Cable (US Type)
Chile Cable (US Type)
Brazil Cable (US Type)
Australia Normal
New Zealand Normal
Egypt Normal
South Africa Normal
PDP506HDG.book Page 51 Monday, June 27, 2005 12:57 PM
