Pioneer PDP-507XA User Manual

PDP-507XD
127
5678
56
7
8
C
D
F
A
B
E
SUS-B ADJUSTMENT
50X MAIN DRIVE Assy
SUS-D ADJUSTMENT
XSUS-U
from
DIGITAL Assy
IC1001_A2
Pin
3
Pin
2
Pin
5
Pin
4
Pin
8
Pin 2
IC1102
IC1205
IC1101
IC1104
X DK
Module
Q1102
TP1106
Coupler
1 Measure the SUS-U input delay time (∆ Tsus-u).
from
DIGITAL Assy
XSUS-B
IC1001_A1
VR1001
Q1210
FET
Q1211
FET
Coupler
IC1204
Q1213
Q1209
TP1260
2 Adjust the SUS-B input delay time so that it becomes "∆ Tsus-u + α ± 5 nsec."
50Y MAIN DRIVE Assy
50Y MAIN DRIVE Assy
YSUS-U
from
DIGITAL Assy
IC2003_A4
Pin 2
IC2102
IC2209
IC2101
IC2107
Y DK
Module
Q2103
TP2105
Coupler
1 Measure the SUS-U input delay time (∆ Tsus-u).
1 Measure the SUS-D pulse width (Tsus-D).
from
DIGITAL Assy
YSUS-B
IC2003_A4
VR2001
Q2210
FET
Q2216
FET
Coupler
IC2208
Q2221
Q2215
TP2276
2 Adjust the pulse width of the SUS-D input signal for
the DK module so that it becomes "Tsus-D ± 5 nsec."
2 Adjust the SUS-B input delay time so that it becomes "∆ Tsus-u + α ± 5 nsec."
from
DIGITAL Assy
YSUS-D
IC2002_A7
Q2106
VR2002
IC2104
IC2107
Y DK
Module
TP2107

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
