Pioneer PDP-507XA User Manual

PDP-507XD
153
5678
56
7
8
C
D
F
A
B
E
8.2.3 OPTION
8.2.4 INITIALIZE
Operation item
8.2.3.1 EDID WRITE MODE
Exclusively used for production line.
8.2.3.2 CH PRESET
Exclusively used for production line.
No. Function Content RS-232C
1 EDID WRITE MODE ⇔ DISABLE ⇔ ENABLE −−−
2 CH PRESET ⇔ USER ⇔ FACTORY −−−
8.2.4.1 SYNC DET (+)
Exclusively used for technical analsyis (details omitted).
8.2.4.2 SG MODE
SG MODE (SG's route selection) / SG PATTERN (signal pattern selection) are used as pair.
In SG MODE, select the SG route and then select the SG pattern to be sent by the selected route.
In SG MODE, make sure to select the route first.
Operation item
No. Function Content RS-232C
1 SYNC DET (+) Exclusively used for technical analsyis. −−−
2 SG MODE ⇔ Paired SG_MODE with SG_PATTERN. Select SG Route. −−−
3 SG PATTERN ⇔ Paired SG_MODE with SG_PATTERN. Select SG Pattern. −−−
4 SIDE MASK LEVEL (+) Configure the color of the side mask. BSL, GSL, RSL
5 FINAL SETUP (+) Initialize flash memorys on virgin product status FST
6 CVT AUTO ⇔ Exclusively used for technical analsyis. −−−
7 HDMI INTR POSITION (+) Exclusively used for technical analsyis. −−−
Operation item
NIITI
GSANA–MVDEC–YMO E < = >D
LAIZE
A–V1 3 1060 –NTV HE–B7
1
5
10
15
16
15 10 15 20 25 30 35 40
No.
Display
Content
1 SG OFF SG Mode is OFF.
2 DIG MVDEC YCBCR MAIN VDEC: YCbCr
(Digital output mode)
3 ANA MVDEC Y MAIN VDEC: Y (Analog output
mode: SG VDEC return setting)
4 ANA MVDEC RGB MAIN VDEC:RGB
5 ANA SVDEC Y SUB VDEC:Y
6 ANA AD YCBCR AD: YcbCr
(Analog output to the RGB SW)
7 ANA AD RGB AD: RGB
(Analog output to the RGB SW)

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
