Pioneer PDP-507XA User Manual

PDP-507XD
154
1234
1234
C
D
F
A
B
E
NIITILAIZE
GSPATERNT<=>
A–V1 3 1060
L
CO OR 1BAR
–NTV HE–B7
1
5
10
15
16
15 10 15 20 25 30 35 40
No. Display
SG Pattern (Brightness
IRE Level/Color)
No. Display
SG Pattern (Brightness
IRE Level/Color)
1 COLOR BAR1 Colorbar (75%) 11 RASTER4 Raster (75% Green)
2 COLOR BAR2 Colorbar (100%) 12 RASTER5 Raster (75% Magenta)
3 RAMP1 Ramp (100% white) 13 RASTER6 Raster (75% Red)
4 RAMP2 Ramp (100% Yellow) 14 RASTER7 Raster (75% Blue)
5 RAMP3 Ramp (75% Green) 15 RASTER8 Raster (– % Black)
6 RAMP4 Ramp (75% Red) 16 10STEP1 10STEP (100% white)
7 RAMP5 Ramp (75% Blue) 17 10STEP2 10STEP (100% Yellow)
8 RASTER1 Raster (100% White) 18 10STEP3 10STEP (75% Green)
9 RASTER2 Raster (75% Yellow) 19 10STEP4 10STEP (75% Red)
10 RASTER3 Raster (75% Cyanide) 20 10STEP5 10STEP (75% Blue)
• During factory mode, choose the correct route when changing.
• Basically, during VDEC SG output, make sure to connect SG output's Y or G to the AVI input terminal of VDEC.
• During SG MODE, turn off the blanking 50IRE setup function.
• During VDEC SG output, set the YC seperation setting to NTSC.
• It is possible to use ANALOG OUT MODE together during DIGITAL OUT MODE.
The Main VDEC can output digital color difference, in which colors will appear.
But the route to VDEC input cannot be analysed therefore care should be taken when using.
Depending on the situation, please use the proper analog/digital output.
• The SG MODE outputs color difference and RGB only. Therefore, in the case of CVBS, only the Y input is used resulting in no color.
This is not a damage result nor error.
• The SG MODE's ANA AD RGB (route to input 525i to AD by RGB) as a set's route, the setting does not exist. For this account the
latter part from MVDEC does not have set values, resulting in having funny colors in colorbar, the brightness changes after
switching, etc.
This is not a damage result nor error.
• Depending on MVDEC's part version, ANA_MVDEC_YCBCR may not display colors.
Notes when using SG MODE/SG PATTERN
Operation item
8.2.4.3 SG PATTERN

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
