9.3.8 QSD
Data Arrangement
Data
Length
Output Example
ECO 3 byte QSD
1 Latest SD data 1 byte 1
2 Latest SD subcategory data 1 byte 0
3 Data from the hour meter for the latest SD 8 byte 00752013
4 Second latest SD data 1 byte 5
5 Second latest SD subcategory data 1 byte 0
6 Data from the hour meter for the second latest SD 8 byte 00495204
7 Third latest SD data 1 byte 2
8 Third latest SD subcategory data 1 byte 3
9 Data from the hour meter for the third latest SD 8 byte 00100355
10 Fourth latest SD data 1 byte 2
11 Fourth latest SD subcategory data 1 byte 5
12 Data from the hour meter for the fourth latest SD 8 byte 00075620
13 Fifth latest SD data 1 byte 1
14 Fifth latest SD subcategory data 1 byte 0
15 Data from the hour meter for the fifth latest SD 8 byte 00000852
16 Sixth latest SD data 1 byte 2
17 Sixth latest SD subcategory data 1 byte 5
18 Data from the hour meter for the sixth latest SD 8 byte 000000451
19 Seventh latest SD data 1 byte 0
20 Seventh latest SD subcategory data 1 byte 0
21 Data from the hour meter for the seventh latest SD 8 byte 00000000
22 Eighth latest SD data 1 byte 0
23 Eighth latest SD subcategory data 1 byte 0
24 Data from the hour meter for the eighth latest SD 8 byte 00000000
CS 2 Byte 7D
Command
Format
Effective Operation
Modes
Function Remarks
[QSD] All operations To acquire data on the shutdown logs Return data: 3 (ECO)+80(DATA)+2(CS)= 85 Byte
The command QSD is for acquiring the data from the 8 latest shutdown (SD) logs.
¶ SD data
0 No SD
1 SQ-IC
2 MDU-IIC
3 RST2
4 TEMP
¶ SD subcategory (SQ-IC)
0 No SD-Sub data
1 Communication error
2 Drive stop
6 Version mismatching
3 BUSY
¶ SD subcategory (MDU-IIC)
0 No SD-Sub data
1 EEPROM
2 BACKUP
3 DAC
¶ SD subcategory (TEMP)
0 No SD-Sub data
1 TEMP1
2 Reserved

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
