8.2.2 PANEL FACTORY MODE
This is the menu screen for the adjustment of the panel. Data acquisition and value adjustment can be performed for
the following items:
No. Indication Description of functions
8.2.2.1 PANEL INFORMATION Data, such as the version of the microcomputer of the panel, product serial number, and
statuses of memories for adjustment values for the main unit and for backup, are
displayed.
8.2.2.2 PANEL WORKS Operation data, such as accumulated pulse-meter count, accumulated hour-meter
count, accumulated power-on count, and the temperature detected by the sensor, are
displayed.
8.2.2.3 POWER DOWN The power-down history is displayed, with the hour-meter values that indicate the hour
values when power-downs occurred.
8.2.2.4 SHUT DOWN
The shutdown history is displayed, with the hour-meter values that indicate the hour
values when shutdowns occurred.
8.2.2.5 PANEL-1 ADJ (+) Settings of the driving pulse timing and driving voltage can be performed.
8.2.2.6 PANEL-2 ADJ (+) White balance and ABL (power consumption) for the panel can be set.
8.2.2.7 PANEL REVISE (+) The level for correction of panel degradation can be set.
8.2.2.8 ETC. (+) Copying of backup data and clearance of various data can be performed.
8.2.2.9 RASTER MASK SETUP (+) The mask indication (RASTER) can be set and indicated.
8.2.2.10 PATTEN MASK SETUP (+) The mask indication (PATTERN) can be set and indicated.
8.2.2.11 COMBI MASK SETUP (+) The mask indication (COMBI) can be set and indicated.
Operation Items

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
