Pioneer PDP-507XA User Manual

PDP-507XD
77
5678
56
7
8
C
D
F
A
B
E
4.18 WAVEFORMS
2ms/div 2ms/div
200ns/div 200ns/div
2ms/div
2ms/div
Color-Bar (MKSS17) Color-Bar (MKSS17)
B/W Checkered pattern (MKSS14) B/W Checkered pattern (MKSS14)
CH1 L1730 L1730
CH2 R1608 R1608
CH3 CLK
––
––
Waveform WaveformMeasuring Point Measuring Point
R ch signal
Resonance waveform (V+ADR) Resonance waveform (V+ADR)
R ch signal
R1637 CLK R1637
CH4 LE R1621 LE R1621
CH5 ADR-D R1720 HBLK R1615
CH6 ADR-B R1714
CH7
Measuring CH
LBLK R1616
50 ADDRESS L Assy Waveform
7
8
1
5
2
3
4
6

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
