8. SERVICE FACTORY MODE
8.1 OUTLINE OF THE SERVICE FACTORY
8.1.1 SERVICE FACTORY MODE TRANSITION CHART
8.1.2 HOW TO ENTER/EXIT SERVICE FACTORY MODE
FACT<AA5F>
POWER<AA1C/AA1B>
FACT<AA5F> FACT<AA5F>
FACT [POF] [FAY] MENU<AA8B>
MENU<AA5B+AF20>
[FAN]
RS-232C Factory mode
INFORMATION
(MTB/MB INFORMATION)
OPTION
INITIALIZE
<AA49>
[ (MUTING)]
Effective 232C command
Effective IR in Factory mode
in Factory mode
Standby mode Power supply ON mode
PANEL FACTORY
The function is changed.
The signal mode is changed.
How to enter Service Factory Mode and do it go out.
How to enter Service Factory Mode.
By using a control unit for servicing)
• Service remote control
: press[FACTORY1]key.
By using RS-232C commands)
• Standby mode : Send [PON]+[FAY] .
• Power supply ON mode : Send[FAY] .
How to come off Service Factory Mode.
By using a control unit for servicing)
• Service remote control : press [ FACTORY1 ] key.
• Remote control : press [ HOME MENU ] key.
By using RS-232C commands)
• Send [FAN] .
