Pioneer PDP-507XA User Manual

PDP-507XD
168
1234
1234
C
D
F
A
B
E
9.3.3 QIP
9.3.4 QAJ
Data Arrangement
Data
Length
Output Example
ECO 3 byte QIP
1 SERIAL 15 byte - - - - - - - - - - - - - - -
2 HOUR METER 8 byte 00000000
3 TOTAL HOUR METER 8 byte 00000000
4 PON COUNTER 8 byte 00000000
5 TEMP1 acquisition (Temperature value) 5 byte +23.5 (*1)
6 TEMP0 acquisition (Temperature value) 5 byte +28.7 (*1)
7 MAX-TEMP1 acquisition (Temperature value) 5 byte +78.3 (*1)
8 Reserved 4 byte ∗∗∗∗
CS 2 byte 94
Command
Format
Effective Operation
Modes
Function Remarks
[QIP] All operations To acquire data on operations of the panel Return data: 3 (ECO)+58(DATA)+2(CS)= 63 Byte
The command QIP is for acquiring data on operational information of the panel.
Note
(*1) : Centigrade scale
Data Arrangement
Data
Length
Output Example
ECO 3 byte QAJ
1 V-SUS adjustment value 3 byte 128
2 V-OFT adjustment value 3 byte 128
3 V-RST-P adjustment value 3 byte 128
4 Reserved 3 byte ∗∗∗
5 XSB adjustment value 3 byte 128
6 YSB adjustment value 3 byte 128
7 YTG adjustment value 3 byte 128
11 RYW adjustment value 3 byte 128
12 R-REVICE setting value 1 byte 0
13 G-REVICE setting value 1 byte 0
8 YTW adjustment value 3 byte 128
9 RSW adjustment value 3 byte 128
10 YTB adjustment value 3 byte 128
14 B-REVICE setting value 1 byte 0
CS 2 byte B7
• For each REVISE setting value, the level set for RRL, RGL, or RBL is transmitted as one character.
Command
Format
Effective Operation
Modes
Function Remarks
[QAJ] All operations To acquire data on operations of the panel Return data: 3 (ECO)+41(DATA)+2(CS)= 46 Byte
The command QAJ is for acquiring the panel's factory-preset data.

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
