Pioneer PDP-507XA User Manual

PDP-507XD
181
5678
56
7
8
C
D
F
A
B
E
10.4 LED INFORMATION
State
AC OFF or
Main power switch OFF
Standby power
management
Power ON
Power-down
Once OnceTwice n times500 msec 2.5 sec
Once OnceTwice n times500 msec
200 msec
200 msec
100 msec
100 msec
2.5 sec
Shutdown
No digital adjustment data
copied for backup
In the process of rewriting
the program of the
microcomputer
PDP- 507XD only
RS-232C <=> SR+ switch
During reservation
video recordings
(Unit: Standby)
During factory operation
During sleep timer operation (∗2)
During reservation video
recordings (Unit: ON) ∗1
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
Blue
Red
Orange
LED Pattern
POWER ON STANDBY REC TIMER
∗1: PDP-507XD types
∗2: PDP-507XA types
LED Pattern

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
