9.3.12 DRV
< No. 2 Subcategory Information on "Failure in IIC communication of Main microcomputer" >
< No. 3 Subcategory Information on "Digital tuner" >
Value Shutdown Factor Remarks (Operation)
0 Non subcategory
1 Analog tuner1 (Front end 1) FE1 (immediately Power Supply OFF)
3 MPX MPX (After 3 times reset action, turn Power Supply off (except for us))
4 AV switch AV-SW (immediately Power Supply OFF)
5 RGB switch RGB-SW (immediately Power Supply OFF)
8 Main VDEC M-VDEC (immediately Power Supply OFF)
9 Sub VDEC S-VDEC (immediately Power Supply OFF)
F M2 busy TX-BSY (After 3 times reset action, turn Power Supply off)
G 64k EEPROM MA-EEP (immediately Power Supply OFF)
H AUDIO IC
A AD/PLL ADC (immediately Power Supply OFF)
B HDMI HDMI (immediately Power Supply OFF)
E M2 communication TX-COM (After 3 times reset action, turn Power Supply off)
Value Shutdown Factor Remarks (Operation)
0 Non subcategory
1 DTV starting failure PS/RST (The history is left, and intercepts it the communication)
2 DTV communication failure RETRY (The history is left, and intercepts it the communication)
< No. 4 Subcategory Information on "POWER" >
Value Shutdown Factor Remarks (Operation)
1 DCDC Converter heden M-DCDC (immediately Power Supply OFF)
2 Relay Power supply heden RELAY (immediately Power Supply OFF)
At standby mode, when 10 seconds passed after
issuing [DRV+S00], command becomes invalid.
Command
Format
Effective Operation
Modes
Function Remarks
[DRV+S00] Every time DRIVE OFF
[DRV+S01] Every time DRIVE ON
Drive ON/OFF: ON/OFF control for only the large-power system
