Pioneer PDP-507XA User Manual

PDP-507XD
8
1234
1234
C
D
F
A
B
E
1.3 JIGS LIST
CONTENTS
1. NOTES ON SERVICE VISIT............................................................................................................................. 2
1.1 SAFETY INFORMATION ........................................................................................................................... 2
1.2 QUICK REFERENCE UPON SERVICE VISIT........................................................................................... 6
1.3 JIGS LIST .................................................................................................................................................. 8
2. EXPLODED VIEWS AND PARTS LIST .......................................................................................................... 10
2.1 PACKING SECTION ................................................................................................................................ 10
2.2 REAR SECTION ...................................................................................................................................... 12
2.3 FRONT SECTION.................................................................................................................................... 14
2.4 CHASSIS SECTION (1/2)........................................................................................................................ 16
2.5 CHASSIS SECTION (2/2)........................................................................................................................ 18
2.6 PANEL CHASSIS SECTION.................................................................................................................... 20
2.7 MULTIBASE SECTION ............................................................................................................................ 22
2.8 PDP SERVICE ASSY 507 (AWU1212).................................................................................................... 24
3. PCB PARTS LIST ........................................................................................................................................... 26
4. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM..........................................................................................42
4.1 OVERALL CONNECTION DIAGRAM (1/2) ............................................................................................. 42
4.2 OVERALL CONNECTION DIAGRAM (2/2) ............................................................................................. 44
4.3 OVERALL BLOCK DIAGRAM (1/2) ......................................................................................................... 46
4.4 OVERALL BLOCK DIAGRAM (2/2) ......................................................................................................... 48
4.5 50 ADDRESS S and L ASSYS ................................................................................................................ 49
4.6 50 SCAN A and B ASSYS ....................................................................................................................... 50
4.7 50X MAIN DRIVE and 50X SUB DRIVE ASSYS..................................................................................... 51
4.8 50Y MAIN DRIVE and 50Y SUB DRIVE ASSYS..................................................................................... 52
4.9 50 DIGITAL ASSY.................................................................................................................................... 53
4.10 AUDIO ASSY ......................................................................................................................................... 54
4.11 SIGNAL BLOCK DIAGRAM ................................................................................................................... 56
4.12 R07 DT ASSY (PDP-507XD ONLY)....................................................................................................... 58
4.13 MAIN ASSY POWER LINE BLOCK DIAGRAM ..................................................................................... 59
4.14 50 X/Y DRIVE POWER LINE BLOCK DIAGRAM.................................................................................. 60
4.15 FUKUGO BLOCK POWER LINE BLOCK DIAGRAM ............................................................................ 61
4.16 POWER SUPPLY UNIT.......................................................................................................................... 62
4.17 VOLTAGES ............................................................................................................................................. 63
4.18 WAVEFORMS ........................................................................................................................................ 77
5. DIAGNOSIS INFORMATION .......................................................................................................................... 81
5.1 THE FLOW OF DIAGNOSIS.................................................................................................................... 81
5.1.1 FLOWCHART OF FAILURE ANALYSIS FOR THE WHOLE UNIT .................................................... 81
5.1.2 FLOWCHART OF FAILURE ANALYSIS FOR THE POWER SUPPLY UNIT..................................... 83
5.1.3 FLOWCHART OF FAILURE ANALYSIS FOR THE DIGITAL ASSY .................................................. 84
5.1.4 FLOWCHART OF FAILURE ANALYSIS FOR THE DRIVE ASSY..................................................... 85
5.1.5 FLOWCHART OF FAILURE ANALYSIS FOR THE MAIN ASSY....................................................... 89
5.1.6 FLOWCHART OF FAILURE ANALYSIS FOR THE VIDEO SYSTEM................................................ 90
5.1.7 FLOWCHART OF FAILURE ANALYSIS FOR THE AUDIO SYSTEM ............................................... 97
5.2 POWER DOWN ..................................................................................................................................... 101
5.2.1 BLOCK DIAGRAM OF THE POWER-DOWN SIGNAL.................................................................... 101
5.2.2 POWER DOWN OF FAILURE ANALYSIS....................................................................................... 102
5.3 SHUT DOWN ......................................................................................................................................... 104
Cleaning
Name Part No. Remarks
Cleaning liquid GEM1004
Used to fan cleaning.
Refer to "2.4 CHASSIS SECTION (1/2).
Cleaning paper GED-008

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
