8.1.3 OPERATION OF SERVICE FACTORY MODE
User data
User data will be treated as follows :
• User data on picture-quality and audio-quality adjustments are not reflected, and factory-preset data are output
(user data will be retained in memory). When the unit enters Service Factory mode, the current audio-quality adjustment
data will be still be retained in memory.
• As to data on various settings, user data will be applied to the items that are associated with signal format change
(screenize switching, etc).
• Data on screen (i.e., screen position; meaning clock dividers, and not including data on screen size).
Are reset to the default values (data stored in memory will be retained).
Screen size will be retained.
Fuctions whose setting are set to OFF
No. Function Remarks
1 2-Screen Operation Input function set on the main side is selected
2 FREEZE
3 Mask Control MTB/MB is none. It becomes processing on the PANEL side.
4 ORBITER Central value operation

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
