Pioneer PDP-507XA User Manual

PDP-507XD
22
1234
1234
C
D
F
A
B
E
2.7 MULTIBASE SECTION
B
D
D
F
F
A
A
SIDE
CN9210
POWER
P5
POWER
P8
POWER
P9
POWER
P3
SIDE KEY CN9501
LED IR CN9701
50 DIGITAL
CN3001
Fan
LED IR
CN9701
50 LED
CN9651
C
B
C
G
E
E
G
1
2
7
14
26
18
9
9
28
4
19
51
50
48
50
47
47
44
40
48
48
35
51
39
34
34
34
32
31
20
11
37
12
21
23
13
31
30
30
29
33
28
8
17
3
38
35
22
5
36
36
49
51
51
51
51
25
15
16
41
51
24
6
10
27
29
45
43
42
PDP-507XD only
PDP-507XD
only
PDP-507XD
only
29
29
PDP-507XD PDP-507XA
PDP-507XD
only
PDP-507XD
only

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
