9.3.13 OTHER COMMANDS
Command
Format
Operation
Remarks
Effective
Operation Modes
Control
[FAJ]
During FAY
To make the flag setting that
indicating that adjustment of the
panel unit has been completed
Writing 00 to the 4 k byte ROM and
copying to the 2 k byte ROM
This takes at least 350 ms.
[UAJ]
To make the flag setting that
indicating that adjustment of the
main unit has not been completed
Writing F0 to the 4 k byte ROM
[CBU]
To make the flag setting that
indicating that backup data
have not been copied
Writing F0 to the 2 k byte ROM The backup ROM is
initialized.
[BCP]
To copy Digital backup data
to EEPROM
Copying backup data
7 Backup function for adjustment values for the main unit • • • [FAJ/UAJ/CBU/BCP]
When the DIGITAL Assy is to be replaced, adjustment values can be copied from the backup EEPROM to the EEPROM
of the Assy for service.
7 Setting for Factory mode permission/prohibition • • • [FAY/FAN]
The commands FAY/FAN are for prohibiting/permitting panel-adjustment commands.
Command
Format
Operation
Remarks
Effective Operation
Modes
Control
[FAY]
Normal operation mode
while the power is on
Adjust command is valid.
Mask indications will be forcibly turned off.
[FAN]
During FAY Adjust command is invalid.

Pioneer PDP-507XA Specifications

General

3D	-
Depth	115 mm
Width	1224 mm
Height	717 mm
Weight	34100 g
Tuner type	Analog
Pixel pitch	- mm
Smart modes	Energy saving
Aspect ratio	16:9
Product color	Black
LED indicators	Y, Power
Noise reduction	Yes
RMS rated power	26 W
AC input voltage	220 - 240 V
Display diagonal	50 \
Channels quantity	99 channels
AC input frequency	50 - 60 Hz
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Number of speakers	2
Teletext standards	Top-text
SCART ports quantity	3
Supported video modes	1080p
USB 2.0 ports quantity	0
Contrast ratio (typical)	4000:1
Annual energy consumption	- kWh
Display diagonal (metric)	127 cm
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL BG, PAL DK, PAL I, SECAM, SECAM B/G, SECAM D/K, SECAM L
Power consumption (standby)	0.3 W
Power consumption (typical)	341 W
Sound enhancement technology	FOCUS, SRS, TruBass
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 768 (WXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Component video (YPbPr/YCbCr) in	1
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE, TUR
